Europa Access Hatches – Grey
The seal ensures weatherproofing when the hatch is mounted on vertical surfaces. Contoured handles provide a positive twist lock action and easy lift grip. Protrusion above deck is only 17mm. Intrusion 20mm. Screw holes are 5mm countersunk. Available in a choice of white, grey or black, with or without key security lock.
BLA Code | Colour | Key Lock | Outside mm | Inside mm | Cut Out mm |
|---|---|---|---|---|---|
| 173312 | White | No | 283 x 375 | 192 x 294 | 200 x 302 |
| 173313 | Grey | No | 283 x 375 | 192 x 294 | 200 x 302 |
| 173314 | White | Yes | 283 x 375 | 192 x 294 | 200 x 302 |
| 173315 | Grey | Yes | 283 x 375 | 192 x 294 | 200 x 302 |
| 173316 | White | No | 375 x 383 | 294 x 294 | 302 x 302 |
| 173317 | Grey | No | 375 x 383 | 294 x 294 | 302 x 302 |
| 173318 | White | Yes | 375 x 383 | 294 x 294 | 302 x 302 |
| 173319 | Grey | Yes | 375 x 383 | 294 x 294 | 302 x 302 |
| 173320 | White | No | 470 x 515 | 378 x 435 | 386 x 443 |
| 173321 | Grey | No | 470 x 515 | 378 x 435 | 386 x 443 |
| 173322 | White | Yes | 470 x 515 | 378 x 435 | 386 x 443 |
| 173323 | Grey | Yes | 470 x 515 | 378 x 435 | 386 x 443 |
| 173324 | White | No | 363 x 600 | 272 x 518 | 280 x 526 |
| 173325 | Grey | No | 363 x 600 | 272 x 518 | 280 x 526 |
| 173326 | White | Yes | 363 x 600 | 272 x 518 | 280 x 526 |
| 173327 | Grey | Yes | 363 x 600 | 272 x 518 | 280 x 526 |
| 173326BLK | Black | Yes | 363 x 600 | 272 x 518 | 280 x 526 |
